Repair manuals for all Mitsubishi engines from 1990 to 2002 [2002]

Description: A complete collection of technical documentation in English for the repair and maintenance of MITSUBISHI gasoline and diesel engines manufactured from 1990 to 2002 (series 4D, 4G, 4M, 6A, 6G, F8, F9). Some engines designed before 2002 were installed on concern cars later, which is also specified in the manuals. (example - 6G7 series)

The publication contains detailed information on diagnostics, repair and adjustment of the engine, elements of the engine management system (MPI fuel injection, ignition, turbocharging, proprietary MIVEC system), starting and charging systems, instructions for using self-diagnosis systems. Possible malfunctions and methods for their elimination, the mating dimensions of the main parts and the limits of their permissible wear, recommended lubricants and working fluids are given. The design changes to which the components and assemblies of engines were subjected during the production process (service letters) are described.

Add. Information: The table of contents is the file "COVER_E.pdf", which contains structured links to all pages of the documentation.

Release year: 2001
English language
Format: PDF
